BaudouinBaudouin 6M26.3
Baudouin 6M26.3 Major Overhaul BOM
Overhaul Kits
Nota del Ingeniero: Esta lista incluye números de parte OEM validados para revisiones de 10,000h (Superior) y 20,000h (Mayor). Las cantidades son por unidad de motor individual.
| Selec. | Sistema | Nombre de Parte | N/P OEM | Cant. |
|---|---|---|---|---|
| Cylinder Head | Cylinder Head Assembly (HPCR) | 1005249141 | 6 | |
| Cylinder Head | Intake Valve | 15012820H | 12 | |
| Cylinder Head | Exhaust Valve | 14011470J | 12 | |
| Cylinder Head | Valve Guide | 15011040Y | 24 | |
| Cylinder Head | Intake Valve Seat | 15012800L | 12 | |
| Cylinder Head | Exhaust Valve Seat | 15012810X | 12 | |
| Cylinder Head | Valve Spring (Inner) | 14010390K | 24 | |
| Cylinder Head | Valve Spring (Outer) | 14010380Z | 24 | |
| Cylinder Head | HPCR Injector Socket | 1001448146 | 6 | |
| Cylinder Head | Cylinder Head Gasket | 15011610S | 6 | |
| Cylinder Head | Head Cover Gasket | 330201000012 | 1 | |
| Piston & Liner | Piston Assembly | 1000443147 | 6 | |
| Piston & Liner | Cylinder Liner | X6260.114 | 6 | |
| Piston & Liner | Piston Ring Set | 13025060Z | 6 | |
| Piston & Liner | Gudgeon Pin | 331002000114 | 6 | |
| Piston & Liner | Liner O-Ring (Top) | 1001525022 | 6 | |
| Piston & Liner | Liner O-Ring (Bottom) | 1001525023 | 6 | |
| Piston & Liner | Piston Cooling Jet | 331001000785 | 6 | |
| Crankshaft | Main Bearing Set | 15510670Z | 1 | |
| Crankshaft | Thrust Bearing Set | 15011780C | 1 | |
| Crankshaft | Connecting Rod | 15520071S | 6 | |
| Crankshaft | Con-Rod Bearing (Std) | 15529010J | 6 | |
| Crankshaft | Camshaft | 15021001A | 1 | |
| Fuel System | HPCR Pump Assembly | 1001590766 | 1 | |
| Fuel System | HPCR Injector | 331005000977 | 6 | |
| Fuel System | Common Rail | 611600080066 | 1 | |
| Fuel System | Fuel Filter (Duplex) | 15050630F | 1 | |
| Fuel System | Feed Pump | 1001739787 | 1 | |
| Cooling | Fresh Water Pump | 1003582001 | 1 | |
| Cooling | Thermostat Assembly | 1001769788 | 1 | |
| Cooling | Intercooler (Two-Stage) | 1005856384 | 1 | |
| Lubrication | Oil Pump | 1004680912 | 1 | |
| Lubrication | Oil Cooler Core | 1000966175 | 2 | |
| Lubrication | Oil Filter | 1000697504 | 3 | |
| Turbocharging | Two-Stage Turbo Assembly | 1005856400 | 1 | |
| Turbocharging | Turbo Inlet Gasket | 330210000069 | 1 | |
| Turbocharging | Turbo Outlet Gasket | 330210000028 | 1 | |
| Turbocharging | Oil Supply Line | 1001791610 | 1 |
